HYDROCARBON SUCTION HOSE
HYDROCARBON SUCTION HOSE
HYDROCARBON SUCTION HOSE
HYDROCARBON SUCTION HOSE
HYDROCARBON SUCTION HOSE
HYDROCARBON SUCTION HOSE

HYDROCARBON SUCTION HOSE

The hydrocarbon suction hose is designed for the suction of fuels, mineral oils and other petroleum derivatives in industrial applications with aromatic content up to 50%.

Applications: Frequent use in tanker trucks, gas stations, ships, etc.

Main features:

  • Inner tube: Smooth black NBR synthetic rubber.
  • Reinforcement: High-tenacity synthetic braid. Steel spiral. Incorporates copper wire for electrostatic discharge.
  • Outer cover: Black NBR/EPDM synthetic rubber resistant to abrasion, weathering, and severe operating conditions. Surface with a fine fabric print.
  • Maximum suction 90%.
  • Temperature: -20ºC to +80ºC (tips up to 100ºC)

The selection is by inner diameter.

Choose full rolls or linear meters, according to your needs.

€12.86 (tax included)
€10.63 (tax excl.)
DIAMETERS
  • Ø 25
  • Ø 30
  • Ø 32
  • Ø 35
  • Ø 38
  • Ø 40
  • Ø 45
  • Ø51
  • Ø 60
  • Ø 63
  • Ø 70
  • Ø 76
  • Ø 80
  • Ø 90
  • Ø 102
  • Ø 114
  • Ø 127
  • Ø 152
DIAMETERS:
metros
metros
Reference:
20581
Description

Hydrocarbon suction hose

The hydrocarbon suction hose is designed for the suction of fuels, mineral oils, and other petroleum products in industrial applications. Its construction incorporates a hydrocarbon-resistant synthetic rubber inner tube , a high-strength textile reinforcement, and a steel spiral that prevents hose collapse during dry operation.

Thanks to its high flexibility and mechanical strength, it is a reliable solution for fuel loading, tank emptying, and storage facility operations. The outer casing offers excellent protection against abrasion, weathering, ozone, and aging, ensuring a long service life even under demanding working conditions.

Applications

The hydrocarbon suction hose is suitable for:

  • Gasoline and diesel aspiration.
  • Transfer of diesel and liquid fuels.
  • Emptying of storage tanks and reservoirs.
  • Loading tanker trucks.
  • Oil installations.
  • Service stations.
  • Ports and fuel terminals.
  • Industrial maintenance equipment.

Technical specifications for the hydrocarbon suction hose:

Reference Inner diameter (mm) Outer diameter (mm) Thickness (mm) Weight (kg/m) Working pressure (bar) Depression (mH2O) Curve radius (mm) Roll length (Mt)
20581 25 35 5.00 0.800 10 9 35 40
20582 30 40 5.00 0.860 10 9 40 40
20583 32 42 5.00 0.900 10 9 45 40
20584 35 45 5.00 1,000 10 9 55 40
20585 38 48 5.00 1,100 10 9 65 40
20586 40 50 5.00 1,250 10 9 68 40
20587 45 56 5.50 1,500 10 9 75 40
20588 51 63 6.00 1,810 10 9 80 40
20589 60 73 6.50 2,150 10 9 85 40
20590 63 76 6.50 2,210 10 9 95 40
20591 70 83 6.50 2,500 10 9 125 20
20592 76 89 6.50 2,920 10 9 155 40
20593 80 93 6.50 3,200 10 9 170 20
20594 90 104 7.00 3,900 10 9 185 20
20595 102 116 7.00 4,250 10 9 200 20
20596 114 130 8.00 5,000 10 9 225 30
20597 127 143 8.00 5,500 10 9 255 30
20598 152 170 9.00 6,900 10 9 280 30
Product Details
20581
