REINFORCED RUBBER FLAT FIRE HOSE
REINFORCED RUBBER FLAT FIRE HOSE
REINFORCED RUBBER FLAT FIRE HOSE
REINFORCED RUBBER FLAT FIRE HOSE
REINFORCED RUBBER FLAT FIRE HOSE
REINFORCED RUBBER FLAT FIRE HOSE
REINFORCED RUBBER FLAT FIRE HOSE
REINFORCED RUBBER FLAT FIRE HOSE

REINFORCED RUBBER FLAT FIRE HOSE

The reinforced rubber fire hose , equivalent to the DURAHOSE or ARMTEX ONE model, is specifically designed for firefighting and hydrant equipment, thanks to its maximum resistance.

Technical specifications:

  • Made of extruded rubber with an inner textile layer made of 100% high tenacity fiber.
  • Color: Brick red
  • Maximum resistance and durability.
  • Water transport in general.
  • Working pressure 15 bar.
  • Service temperature: -30ºC / +80ºC
  • Complies with UNE-23-091-90 -2nd standard, AENOR certified.

SUPPLIED AS STANDARD WITHOUT FITTINGS. Custom fittings available upon request with Guillemin, Storz, Barcelona, etc.

It is supplied in a 60m roll for Ø25 and Ø45

It is supplied in a 20m roll for Ø65 and Ø70

€332.91 (tax included)
€275.13 (tax excl.)
DIAMETERS
  • Ø 25
  • Ø 45
  • Ø 65
  • Ø 70
Reference:
20660027
Description

Reinforced rubber fire hose

The reinforced rubber fire hose is designed for water propulsion in firefighting installations, offering a flexible, durable and safe solution for situations where a rapid supply of pressurized water is required.

Its flat design when not in use facilitates storage and transport, while its reinforced structure allows it to withstand high pressures during use.

Technical specifications

  • Flat and flexible design for easy rolling and storage
  • High resistance to service pressure
  • High-tenacity interior textile reinforcement
  • Good resistance to abrasion and wear
  • Heavy-duty outer cover

Common applications

  • Fire suppression systems
  • Fire hose reels (BIE)
  • Emergency vehicles and equipment
  • Industrial facilities
  • Agriculture and emergency irrigation
  • Temporary drainage and pumping

Technical specifications of a reinforced rubber flat fire hose:

Code Inner diameter (mm) Thickness (mm) Working pressure (bar) Bursting pressure (bar) Weight kg/m Roll length (m)
20660027 25 1.9 40 120 0.21 60
20660039 45 2 21 63 0.37 60
20660040 65 2.2 18 53 0.59 20
20660047 70 23 18 52 0.66 20
