A Prevost 0.01 micron MFS submicron filter is used to remove extremely fine contaminants from compressed air, ensuring superior air quality for sensitive applications.
Applications: High-quality paint, Pharmaceutical and food industry, Medical equipment, Analytical instrumentation, High-precision industrial processes.
Technical specifications:
The Prevost 0.01 micron MFS submicron filter provides high-precision filtration, retaining extremely small particles and contaminants present in pneumatic circuits. With a filtration rating of 0.01 microns , it is designed for applications requiring a high level of compressed air cleanliness.
Suitable for pneumatic installations and compressed air treatment systems where high-precision filtration is required. It can be used to protect sensitive equipment and components, such as valves, actuators, pneumatic tools, and other items that need a clean air supply.
Technical specifications of a Prevost 0.01 micron MFS submicron filter:
| Reference | Thread | Flow rate at 6 bar (m3/h) | A (mm) | B (mm) | C (mm) | D (mm) | E (mm) |
| 34140003 | 1/2" | 55 | 90 | 289 | 230 | 19 | 19 |
| 34140004 | 3/4" | 55 | 140 | 415 | 335 | 31 | 31 |
| 34140005 | 1" | 225 | 140 | 443 | 365 | 31 | 31 |
| 34140006 | 1-1/2" | 300 | 140 | 519 | 432 | 31 | 31 |
| 34140007 | 2" | 500 | 151 | 556 | 465 | 25 | 25 |
| 34140008 | 2-1/2" | 1550 | 240 | 752 | 660 | 25 | 25 |
