ISO-7241-B PUNCH PLUG

ISO-7241-B PUNCH PLUG

The ISO-7241-B punch plug is the male part of a quick coupling that complies with the ISO-7241 Series B standard. Its function is to provide quick connection and disconnection of fluid lines without the use of tools and with minimal fluid loss.

Applications: Agricultural machinery, Construction and earthmoving, Pneumatic tools, Industrial process lines.

Technical specifications:

  • Made of carbon steel.
  • NBR gasket PTFE ring
  • Service temperature -20º / 100ºC
€19.61 (tax included)
€16.21 (tax excl.)
SELECT THE THREAD
  • 1/8"
  • 1/4"
  • 3/8"
  • 1/2"
  • 3/4"
  • 1"
Reference:
46020005
Description

ISO-7241-B punch plug

The ISO-7241-B Punch Plug is a hydraulic quick coupling designed for safe and efficient connections and disconnections in medium- and high-pressure hydraulic circuits. Manufactured in accordance with ISO 7241 Series B, it ensures dimensional compatibility with other couplings that meet this standard and is widely used in industrial, chemical, and mobile machinery applications.

Its punch valve design minimizes fluid loss during connection and disconnection, helping to maintain the cleanliness of the hydraulic circuit and reducing maintenance time.

Applications

The ISO 7241-B punch plug is commonly used in:

  • Industrial hydraulic systems.
  • Construction machinery.
  • Agricultural equipment.
  • Handling equipment.
  • Chemical and process industry.
  • Mobile hydraulic systems.
  • Maintenance and repair teams.

Technical data sheet for an ISO-7241-B Punch Plug:

Product Details
46020005
