LIMIT SWITCH SENSOR

A limit switch is a device used to detect the limit or end position of a moving element.

Applications: mechanical, pneumatic or automated systems.

Main features:

It detects a pressure drop by emitting a command signal (S).
Primarily used as a pneumatic limit switch in actuators, mounted directly on the actuator it detects the end of the stroke by sending a pilot signal to the pneumatic valve and reversing the direction of the actuator or by actuating another control valve.
The cylinder needs to complete its full stroke.
It is possible to fit a regulator (PREG) on the top in order to regulate the exhaust to control the speed of the stem.

€26.90 (tax included)

€22.23 (tax excl.)

SELECT THE THREAD

1/8"
1/4"
3/8"

Reference:

15150004

Description
Comments

Description

End-of-travel sensor

A limit switch is a device used to detect the limit or end-of-travel position of a moving element within a mechanical, pneumatic, or automated system.

Its main function is to send a signal when a component, such as a cylinder, shaft or mechanism, reaches a certain position, allowing a movement to be controlled, stopped or reversed within the process.

Applications

Pneumatic and hydraulic cylinders
Industrial machinery
Automated lines
Positioning systems

Technical specifications of a limit switch sensor:

CAPTADOR FINAL DE CARRERA

Product Details

Reference 15150004
